Product

ZR-10C-Hydrophilic-Emulsifier
MAGNAFLUX Zyglo ZR-10C Hydrophilic Emulsifier, Content: 25 Litres
Magnaflux 10 Gauss Filed Indicator
Magnaflux 10 gauss calibrated field indicator Meter, Part # 505056, Made in UK

MAGNAFLUX 20 GAUSS CALIBRATED FIELD INDICATOR METER, PART # 105645, MADE IN UK

Magnaflux 20 Gauss Calibrated Field Indicator

The Magnaflux 20 Gauss Calibrated Field Indicator is for general purpose use as may be required in various demagnetization specifications. Scaled +20 or -20 gauss from 0 center with large divisions at 2 gauss and small divisions at 1 gauss. The gauss field indicator will withstand exposure to fields as strong as 400 oersteds without affecting calibration and is accurate to +/- 1.0 gauss. Certification is provided with each meter.

Specifications Compliance:

  • ASME BPVC
  • ASTM E709
  • ASTM E1444

Part # 105645
Made in UK
Quantity: One Piece

In Stock

Sku:1457

Request A Quote
Compare

Magnetic field indicators

This range of field indicators is to help you check and measure magnetic field strength and direction during the magnetic particle inspection process. They provide flexibility in measuring residual part magnetism, field direction and AC/DC field strength in mag particle testing applications.

Calibrated Field Indicators :

  • Rugged, pocket-size meters used to indicate residual magnetism remaining in part after magnetisation. Certification is provided.

Non-calibrated Field Indicator :

  • Rugged, pocket-size meters used to indicate residual magnetism remaining in part after magnetisation. Inexpensive, disposable, non certified field indicator.

ASME Field Indicator :

  • Use the ASME Field Indicator to gauge the strength and direction of your magnetic field. Designed in accordance with ASME Boiler and Pressure Vessel Code Section V, Article 7.

Applications

Ideal Application : Check and measure magnetic field strength and direction, and residual part magnetism during the inspection process

TDS

Magnetic-Field-Indicators_Product-Data-Sheet_English

Field Indicator Video

Your custom content goes here. You can add the content for individual product
